Panel Cuts

Submitted by Atelier Bump on Wed, 2017-03-01 08:04
0 votes
Version:
1.0.0+
Date Updated:
03/01/2017

Tool for creating panel cuts reports. Useful for furniture or kitchen cabinets design.

Features

  • Material finish, part type, description, grain orientation properties.
  • Sheet use report.
  • Export a .csv file with Part quantity, dimensions, finish, grain direction, part and description values. It can be exported later in spreadsheet or cut optimization softwares.

Help / user guide

Included in GitHub repo

Additional Info:

Install notes

1- Copy scripts, usericons and usermacros to 3ds Max user folder. Normally located at: C:\Users\USER_NAME\AppData\Local\Autodesk\3dsMax\20XX - 64bit\ENU

2- Restart Max if opened

3- Add the macro to a toolbar. It can be found under the category "HAG tools"

Version Requirement:
2014+
