rapidTools toolset

19 votes
Version:
v1.14
Date Updated:
03/26/2016
Author Name:
pi3c3

The Download is now live on the rapidTools website!

*** If you can't reach my website, try using ultrasurf, which is a free VPN extension for google chrome ***

Hi! I first wanted to make this script pack commercial, but later I decided, to make them free, because I realized I'm not a business man, and I'm much more pleased with a few thanks... :) The script pack contains a couple of things I'm using for my modeling pipeline, made especially for quad modeling. But let the videos talking instead of me! Enjoy! :) You can download the pack from my website... ;)

All the scripts are hoteky based, or at least I very recommend to put them on to shortcuts. Watch the tutorial videos to get know how they work.

NEW FEATURES: (description below. tutorial videos under the link, or on the youtube channel)

  • fastWorkingPivot now working on edge selection, using the edge as a direction vector
  • fastWorkingPivot now working on spline objects as well
  • fastPanelizer now saves values individually for every objects
  • rapidRTConform now reselect conformed object after action
  • projection direction now properly working
  • changelog now opens after installation
  • fastUnion, fastIntersect and fastSubstract added to the package

UPDATES / BUGFIXES:

  • rapidQCap: bugfix, when tried to solve improper border, max hanged up due to an infinite loop
  • fastPanelizer: settings now properly working on every object

The package contains the following scripts:

RAPID TOOLS:

rapidQCap v2.0 is a bilinear interpolation base quad capping tool, that let's you cap the desired border edges. The tool is very simple to use as always. Just select the border, and press the hotkey. If the tool can't find the corner vertices, you can select them manually. The v2.0 version has been extended by a corner searching algorithm, and the whole script works on multiple selection as well.

rapidMeshCleanUp is a pretty usefule mesh cleanup tool, that searches for the following:

  • concave faces
  • faces with zero area
  • edges with zero legth
  • triangles
  • nGons
  • mid-edge vertices

The script runs through the mesh, puts an Edit Poly modifier named from the anomaly and selects them.

rapidNGonSolver has been designed to solve the hexagons, octagons and concave faces left behind by Quad Chamfer.

rapidQuadConnect is a way of connecting edges properly. If two rings cross each other, it create quads instead of 4 triangles. It also properly connects corners, where ring changes direction.

rapidRTConform is designed to conform one mesh to another. It is possible to conform just the base of the mesh, if you made your modifications on an EditPoly modifier. You can also change the vertex projection directions based on surface normals.

rapidSoftSelectionManager is designed to save softSelections and load them back. You can also make different kind of operations with selections, like adding, substracting, multiplying and dividing selections.

rapidSplineFFD is a tool that is deisnged by other scripters as well. This variant of splineFFD that let's you control your loops by splines, and adds additional functionality that let's you control the distribution of vertexes over the spline. It also let's you easily save the splines for later use, until the toplogy or vertex order does not change.

rapidVertSplitter creates a topology like inset.

rapidToolsMenuGenerator collects all of the rapidTools scripts and creates a menu for them.

FAST TOOLS SNIPPETS:

  1. fastAttach - (select and attach)
  2. factBridge - (bridge to hotkey without dialog)
  3. fastBorderSelect - (let's you the select the selection border. Selection to selection border)
  4. fastEdgeLoopReguralizer - (edge loop regularizer that makes a loop round, working with Edit Poly as well)
  5. fastEdgeWeightRegularizer - (reduce edge weight so, it avoids the possibility of overlapping faces)
  6. fastExtrude - (single click extrude like edge extrude)
  7. fastMassiveOBJExporter - (Save max file, than run the script. Exports every selected objects into individual OBJ files)
  8. fastPanelizer - (creates simple panels into surfaces, separate them, and sets up the smoothing groups for quadChamfering)
  9. fastPutWorkingPivot - (locks the working pivot where seleciton pivot is in vertex mode)
  10. fastPutObject - (scatters the desired object(s) all over the selected vertices, if there are more objects you want to scatter, just group them, to get a randomized scatter)
  11. fastWorkingPivot - (it aligns the orientation of the pivot to face normals)
  12. fastZeroWeld - (it performs a simple weld with 0,001 threshold)
  13. fastZeroWeldElement - (does the same, but avoids mergeing different elements)
Version Requirement:
2012+
Video URL:

Comments

Comment viewing options

Select your preferred way to display the comments and click "Save settings" to activate your changes.
caypiranha's picture

Hi pi, First thanks for this

Hi pi,

First thanks for this toolsset! Much appreciating for this.
Q: wondering about the panelizer works. In your tutvid, I saw
simply select edges on sphere and then you have while adding the "Quadchampfer" on top.
Does it also work with the regular champfer? Mine does not react in the moment. It does nothing at this step here on my screen.

Thanks in advance for any reply!

pi3c3's picture

If you cannot reach my website!

If you can't reach my website, you can use ultrasurf, which is a VPN extension for chrome. Then you probably can reach my website and download the script pack.

Marcelo Baglione's picture

rapidToolsInstaller_v1.12

pi3c3, hi,

I got the version rapidToolsInstaller_v1.12. Is this the correct and updated?
I am awaiting your return

Marcelo

Marcelo Baglione's picture

rapidTools toolset

Dear pi3c3, hi,

The link that you sent, don´t opening for download. Please, send me another link, please.
Thanks,

Marcelo
